Prokit's Industries MT-3109 - Manual (Page 16)

MT-3109 AC/DC Digital Clamp Multimeter
Specifications
A. General Specifications:

Maximum Voltage between any Terminals and grounding:
Refer to different range input protection voltage.
 Display: 3 3/4 digits LCD display, Maximum display 3999
 Polarity: Automatically display.
 Overloading: Display OL or -OL
 Battery Deficiency: Display
 Measurement Speed: Updates 3 times/second.
 Measurement Deviation: The conductor being measured
is not placed in the center of the jaw during AC/DC current
measurement, it will cause extra +1 % deviation based on
the stated accuracy.
 Max. Jaw Size: 30mm diameter.
 Projected Max. Current conductor size: 30mm diameter.
 Electro-Magnetic: When carrying out measurement near
the electro-magnetic, it may cause unstable or wrong
reading.
 Power: 3x1.5V battery ( AAA) (not included)
 Battery Life: typically 150hours (alkaline battery)
 Sleep Mode (can be disabled)
 Dimensions (H x W x 1): 203mm x 68mm x 33mm
 Weight: Approximate 235g (battery included)
B. Environmental Requirements

The Meter is suitable for indoor use.
 Altitude: Operating: 2000m
 Storage: 1OOOOm
 Safety/ Compliances: IEC 61010 CAT.II 600V over voltage
and double insulation standard.
 Temperature and humidity:
Operating: O℃~30℃(~ 85%R.H);
30℃~40℃ (~ 75%R.H);
40℃~50℃ (~ 45%R.H);
Storage: -20℃~+60℃ (~ 85%R.H)
15
