fast-blown fuse
Frequency response: (40~200)Hz
Display: average value response (RMS of sine wave)
2-3-5.（Ω）
Range Accuracy Resolution
200Ω ±(0.8%+5d) 0.1Ω
2kΩ 1Ω
20kΩ 10Ω
200kΩ 100Ω
2MΩ
±(0.8%+3d)
1kΩ
20MΩ ±(1.0%+25d) 10kΩ
200MΩ ±(5.0%+30d) 100kΩ
Open circuit voltage: less than 0.7V
Overload protection: 250V DC and AC peak value.
Note: At Range 200Ω, short-circuit the test lead to test the wire
resistance, and then subtract it from the real measurement.
WARNING: DO NOT input any voltage at resistance
range for safety!
2-3-6.(C)
Range Accuracy Resolution
2nF ±(2.5%+20d) 1pF
20nF ±(2.5%+20d) 10pF
200nF ±(2.5%+20d) 100pF
2uF ±(2.5%+20d) 1nF
20uF ±(5.0%+10d) 10nF
• Overload protection: 36V DC or AC peak value
WARNING: DO NOT input any voltage at this range for
safety!
