3
2-3-2.(ACV)
Range Accuracy Resolution
2V 1mV
20V 10mV
200V
±(0.8%+5d)
100mV
750V ±(1.2%+10d) 1V
Input Impedance: 10 MΩ at all the ranges.
Overload protection: 1000V DC or AC peak value.
Frequency Response: （40~200）Hz at the Range below 20V
（40~100）Hz at the Range 200V~750V
Display: average value response (RMS of sine wave)
2-3-3.（DCA）
Range Accuracy Resolution
2mA 1uA
20mA
±(0.8%+10d)
10uA
200mA ±(1.2%+8d) 100uA
10A ±(2.0%+5d) 10mA
Max input voltage drop: 200mV
Max input current: 10A (less than 10 seconds)
Overload protection: 0.2A/250V self-resettable fuse, 10A/250V
fast-blown fuse
2-3-4.（ACA）
Range Accuracy Resolution
20mA ±(1.0%+15d) 10uA
200mA ±(2.0%+5d) 100uA
10A ±(3.0%+10d) 10mA
Max measurement voltage drop: 200mV
Max input current: 10A (less than 10 seconds)
Overload protection: 0.2A/250V self-resettable fuse, 10A/250V
