6
squeezing the wire. In case of PLCC or small components such as chip
resistors, desolder by using tweezers, etc.
3. Hold the heat gun up on the SMD components, but do not touch the
components, and allow the hot air to melt the solder. Be careful not to
touch the leads of the components with nozzle.
4. When the soldering tin is melted, remove the SMD components by
lifting the pick up puller (Fig. 5)
5. After removing SMD components, remove residual soldering solder tin
with desoldering tool.
●SMD rework operation instructions
1. Apply proper quantity of solder paste and install the SMD components
on PCB.
2. Refer to (Fig. 6) to preheating components
3. Heat the lead frame evenly (Fig. 7)
Fig. 5
Fig. 6
Fig. 7
