5
C. Electrical Connection and Power ON
●Place the heat gun on the holder.(Fig3)
Fig3
●Loosen the pump securing screw which on the bottom of control station.
(See below pictures)
●Insert the power plug into socket
●Turn on the power switch and the lamp will be lit
●Don‘t pull out the power plug instantly after turning off the power switch,
because the fan keeps operating to protect heat element. Until the fan
stops operation completely, the power plug should not be pulled out.
III. Operation instructions (SMD rework)
●Remove SMD components (such as QFP, SOP, PLCC and so on)
1. Adjust air flow and heat gun temperature to desired level
2. Slip the pick-up puller (optional part)
under the component lead. (Fig. 4) If
the width of the component does not
match the size of the pick-up, adjust
the width of the pick-up by
Fig. 4
