Sena Bluetooth SPH10H v4.2 User's Guide - Manual (Page 34)

35
SPH10H
English
Case 5
• iPhone for mobile phone call
• iPod Touch for stereo music streaming
• TomTom
® Rider2 for GPS voice instruction
• SPH10H for two-way intercom
iPhone
iPod
Touch
Mobile
Call
GPS
Voice
Pairing: 7.2
Pairing: 6.3.1
Pairing: 6.2 Pairing: 8.1
Music
Intercom
Conversation
TomTom ® Rider 2
SPH10H SPH10H
Case 6
• iPhone for mobile phone call and stereo music
streaming
• Sena SR10 for two-way radio, GPS voice instruction,
and radar detector alarm
• SPH10H for two-way intercom
GPS with
headphone
jack/audio
line-out
iPhone
Two-way radio
Radar Detector
Sena SR10
Pairing: 6.1
Pairing: 6.4
Pairing: 8.1
Tow-way radio
GPS Voice
Alarm
Intercom
Conversation
Wired
Connection
Wired
Connection
Wired
Connection
Mobile
Call
Music
SPH10H
SPH10H
