ISSUED: 05-13-11 SHEET #: 145-9012-8 2013-06-25

6

7

Open pull-out mount assembly (

A) by releasing locking tab. Push or pull up on locking tab as shown below.

NOTE: Extended position is for service access only. The mount must be closed during normal use and operation.

Open and Close Pull Out Mount Assembly

A

A

Display cables can be routed through top or bottom of pull-out mount assembly (

A).

NOTE: Use mesh sleeve (M) and cable ties (L) for cable management.

NOTE: Cable ties and cable management slots on pull-out mount assembly (A) can be used to secure display

cables.

Cable Management

DETAIL 3

CABLE MANAGEMENT

SLOTS

LOCKING TAB

LOCKING TAB

PULL UP

PUSH UP
