Parts list, A (1), H (1) – Peerless-AV HCC101 - Installation User Manual
Page 5: C (1), G (4), E (1), F (2), D (1), B (1)
5
2012-09-20 #:009-9075-2 (2013-03-11)
A (1)
main assembly
HCC101
Description
Qty Part #
A
main assembly
1
009-S7610
B
HCACC507 adapter bracket
1
009-1638
C
security lock
1
565-0066
D
HCACC507 laptop tray
1
ACC329
E
HCACC507 USB powered fan
1
ACC329
F
HCACC507 square pad
2
ACC329
G
HCACC507 screw knob
4
ACC329
H
scanner bracket
1
009-S7479
Parts List
H (1)
scanner bracket
C (1)
security lock
G (4)
screw knob
E (1)
USB powered fan
F (2)
square pad
D (1)
laptop tray
B (1)
adapter bracket
Parts (Before beginning, make sure you have all parts shown below)
Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes)
Pièces (avant de commencer, assurez-vous d’avoir toutes les pièces illustrées ci-dessous)
ENG
ESP
FRN
