ISSUED: 10-08-09 SHEET #: 120-9071-2 11-05-09

Max Load Capacity per Arm: 17.5 lb (8 kg)

Installation and Assembly:

Laptop Shelf

Model: ACC328

Note: Read entire instruction sheet before you start installation and assembly.

For customer care call (800) 865-2112 or (708) 865-8870.

Parts may appear slightly different than illustrated.

Before you begin, make sure all parts shown are included with your product.

A

Parts List

Description

Qty.

Part Number

A laptop shelf

1

021-1040

B plastic cover

1

600-0120

C plastic edging

1

600-0121

D 3" rubber edging

2

600-0122

e washer

8

540-1001

F M4 x 16 mm screw

4

520-1119

G M4 nylock nut

4

530-1055

G

F

e

D

C

B

Compatible with models (sold separately):
LCT-A1B1C, LCT-A1B1H, LCT-A1B4C, LCT-A1B4H
