Features

background image

Features:

• Screen adapter plate simply hooks onto the wall plate for quick and easy installation
• Adjustable up to 15° of forward tilt and up to -5° backward tilt
• Tilt angle can be locked with simple tightening of mounting screws
• Colors: Gloss Black
• Includes hardware for installation to wood studs, concrete, and cinder block

Installation and Assembly:

Paramount™ Tilt Mount for LCD Screens

PT630

PT632

©

UL

US

C

ID

: 000001876

2

Model #

Screen Size Range

Max Load Capacity

10" - 24" (25 - 61 cm)

80 lb (36.3 kg)

22" - 40" (56 - 102 cm)

115 lb (52.2 kg)

PT630

PT632

ISSUED: 11-19-07 SHEET #: 202-9245-2 07-28-09
