Description Qty. Part #
A wall arm assembly 1 095-1828
B adapter bracket 2 095-1787
C wood screw 4 520-1202
D concrete anchor 4 590-0320
E portrait lock clip 4 095-1734
F fastener caps 4 590-1324
G cable ties 8 590-1168
H M5 x 13mm self tapping screws 4 520-1616
I M5 flat washers 4 540-1040
J 5 mm allen wrench 1 560-9640
K 6.75" cable cover 2 095-1818
L 4.25" cable cover 2 095-1817
M #3 screwdriver bit 1 560-0209
N 5/32 allen wrench 1 560-9646
Parts List
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.
