Attaching Metal Shelf
Attach shelf pan (P) to shelf support (C) using six 8/32 nylock nuts (O) as shown below. Use an adjustable wrench
to tighten six 8/32 nylock nuts (O).
O
P
C
• This shelf is intended for use with equipment
weighing no more than 50 lbs. (22.7 kg) that fi ts
evenly accross the surface of shelf pan (P). Use with
other equipment may result in instability and cause
personal injury or property damage.
WARNING
6
