Peerless-AV LCZ-3F419B - Installation - Manual (Page 3)

3 of 23 ISSUED: 04-05-11 SHEET #: 090-9199-3 05-29-12
C
D F G
H
E
K
L
J
I
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.
A
B
Description Qty
A base 1
B mounting bracket 3
C pole 1
D lock collar 1
E crossbar 1
F M4 x 12mm screw 12
G M4 x 30mm screw 12
H spacer 12
I knob 3
J cable clip 1
K 3mm allen wrench 1
L 4mm allen wrench 1
Parts List
