Description Qty. Part #
A main tube 2 580-1159
B base 1 104-1055
C carriage 1 104-1063
D adapter plate 2 104-1065
E base cover 1 104-1068
F cable access cover 1 130-1153
G M5 x 8 mm socket pin screw 2 520-1062
H M4 x 10 mm phillips screw 4 504-9012
I M4 x 20 mm 4 504-9020
J M6 x 12 mm pan head 4 520-1128
K M6 x 20 mm phillips screw 4 520-9402
L M6 x 30 mm phillips screw 4 510-9109
M 128 x 313 x 437H retaining spacer 4 590-5005
N M10 x 15 mm socket screw 4 520-9262
O M6 x 20 mm serrated washer head socket pin screw 4 510-9554
P bumper strip 1 570-1030
Q 5/16-24 x 1/4 set screw 8 520-9566
R 6 mm allen wrench 1 560-9716
S 4 mm allen wrench 1 560-9646
T M5 x 10 mm socket pin serrated washer head 1 510-1126
