Peerless-AV MDJ721 - Installation User Manual
Page 4
ISSUED: 06-26-00 SHEET #: 139-9009-2 12-02-04
Visit the Peerless Web Site at www.peerlessindustries.com
For customer service call 1-800-729-0307 or 708-865-8870.
4 of 5
MDJ 701
32" (approx. width - 30" )
3
120"
99.5"
2
3
2
5
MDJ 701
40" (approx. width - 38 ")
3
120”
99.5"
2
3
2
5
MDJ 711
42" (approx. width - 40 ")
3
180"
99.5"
2
3
2
5
MDJ 711
50" (approx. width - 48 ")
3
180"
99.5"
2
3
2
5
MDJ 701
32" (approx. width - 30" )
4
120"
99.5"
2
4
2
6
MDJ 711
40" (approx. width - 38 ")
4
180”
99.5"
2
4
2
6
MDJ 711
42" (approx. width - 40 ")
4
180”
99.5"
2
4
2
6
MDJ 721
50" (approx. width - 48 ")
4
240"
150"
2
4
2
6
X = minimum spacing between plasma screens from center to center
*ADD
COLUMNS
REQ.
PLASMA
QTY.
MODEL # PLASMA SCREEN SIZE
PLCM-2
QTY.
PIPE
LENGTH
PIPE
RADIUS
**EXT / ADJ
COLUMNS
REQ.
CEILING
DECOUPLERS
ACC 600
REQ.
**EXT and ADJ columns are used for attachment to PLCM-2.
*ADD columns are used for attachement to ceiling decouplers only.
Note: Formula assumes approximately 5" between plasmas.
W = width of plasma screen
3
4
X = W + 5
Ceiling Decoupler
ACC 600
Fixed or Adjustable Extension
Columns (ADD models)
Note: Number of columns
needed are listed above. See
page 5 for column placement.
PLCM-2 mount
ACC 600
A
Fixed (EXT models) or
Adjustable (ADJ models)
Extension Columns
X
