Peerless-AV PRS-UNV - Installation - Manual (Page 2)

ISSUED: 09-19-05 SHEET #: 055-9441-10 06-04-11
Visit the Peerless Web Site at www.peerlessmounts.com
2 of 12
For customer care call 1-800-865-2112 or 708-865-8870.
Table of Contents
Parts List.............................................................................................................................................................................3
Installation to Extension Columns / Ceiling Plate ...............................................................................................................4
Installation to Wood Joist Ceilings ......................................................................................................................................5
Installation to Concrete Ceilings .........................................................................................................................................6
Installation to Threaded Rods .............................................................................................................................................7
Attaching Adapter Plate to Projector...................................................................................................................................8
Projector Alignment ..........................................................................................................................................................10
Accessories ................................................................................................................................................................ 11, 12
Tools Needed for Assembly
• stud fi nder ("edge to edge" stud fi nder is recommended)
• phillips screwdriver
• drill
Note: Read entire instruction sheet before you start installation and assembly.
• 5/16" bit for concrete surface
• 5/32" bit for wood studs
• level
WARNING
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US
customers please call Peerless customer care at
1-800-865-2112, for all international customers, please contact your local distributor.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
• Never exceed the Maximum UL Load Capacity. See page one.
• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of an
"edge to edge" stud fi nder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws fi rmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal
injury.
• This product was designed to be installed on the following wall construction only;
WALL CONSTRUCTION HARDWARE REQUIRED
• Wood Stud Included
• Wood Beam Included
• Solid Concrete Included
• Metal Stud Contact Qualifi ed Professional (Not Evaluated By UL)
• Brick Contact Qualifi ed Professional (Not Evaluated By UL)
• Other or unsure? Contact Customer Service
