Warning, Detail 1 b d c – Peerless-AV MDJ760 - Installation User Manual
Page 4
ISSUED: 06-26-00 SHEET #: 139-9010-3 12-02-04
Visit the Peerless Web Site at www.peerlessindustries.com
For customer service call 1-800-729-0307 or 708-865-8870.
4 of 5
A
ACC 600
Fixed or Adjustable Extension
Columns (ADD models)
PLCM-2 mount
Ceiling Decoupler
Ring Extender Pipe
Fixed (EXT models) or
Adjustable (ADJ models)
Extension Columns
MDJ 760
32" (approx. width - 30" )
3
48"
1
3
1
3
MDJ 760
40" (approx. width - 38 ")
3
48"
1
3
1
3
MDJ 760
42" (approx. width - 40 ")
3
48"
1
3
1
3
MDJ 760
50" (approx. width - 48 ")
3
48"
1
3
1
3
MDJ 760
32" (approx. width - 30" )
4
48"
1
4
1
4
MDJ 760
40" (approx. width - 38 ")
4
48"
1
4
1
4
MDJ 760
42" (approx. width - 40 ")
4
48"
1
4
1
4
4
PIPE
DIAMETER
PLASMA SCREEN SIZE
*ADD
COLUMNS
REQ.
PLCM-2
QTY.
3
**EXT and ADJ columns are used for attachment to PLCM-2.
*ADD columns are used for attachement to ceiling decouplers only.
ACC 600
REQ.
ACC 600 Approx. spacing
(center to center for plasmas)
End of one ring extender pipe
90° / 36"
**EXT / ADJ
COLUMNS
REQ.
CEILING
DECOUPLERS
PLASMA
QTY.
MODEL #
Slide
circular pipe (A) and fiber washer (C) over end of
extension column (sold separately).
Thread retaining collar
(B) onto threaded end of
extension column.
Tighten four or
five complete turns. Insert and securely tighten one M5 x .8 x
10 mm self-tapping phillips screw (D) as shown in detail 1.
• The M5 self-tapping phillips screw is essential for
safety. Be sure to lock retaining collar into place with
this screw.
WARNING
DETAIL 1
B
D
C
