Routing Cables

Routing Cables through PRGS projector mount and wall arm assembly: Guide projector cables into
openings in projector mount and wall arm assembly as shown below. Insert Tube Cap (F) into end of wall arm (A).

Note: Cables must be removed from projector before routing through wall arm.

Note: Follow projector mount (PRGS) instructions to install projector.

PROJECTOR CABLES
