Peerless-AV MIS377 - Installation - Manual (Page 5)

ISSUED: 03-16-07 SHEET #: 124-9213-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
5 of 6
Supporting Surface
E
B
3
NOTE: Arrow on wall mount faces up.
Attach four 1/4 x 2.5” phillips screws (E) through wall mount (B) to supporting surface.
4
Attaching wall mount to surface
Attaching Screen Plate
NOTE: Arrow on screen plate faces up.
Attach four M4 x 16 mm socket pin serrated washer head screws (C) through screen plate (A) to
screen using 4mm security allen wrench (F).
SIDE VIEW
Screen
C
D
ARROW
ARROW
A
