To verify mount compatibility with any flat panel display or projector model use MountFinder
TM
at www.peerless-av.com
97
CALL: 630-375-5100
800-865-2112
ONLINE:
www.peerless-av.com
FAX: 630-820-8537
800-359-6500
E-MAIL:
[email protected]
Curvilinear
Circular
In-line
See page 191 for details
IN-LINE
Display Size
Number of
displays
MDJ model
PLCM-2
display mount
PLP display adapter plate
(see MountFinder
TM
)
EXT or ADJ extension column
(connects PLCM-2 to ACC600)
ACC600 interface
bracket to MDJ mount
ADD support
extension column
DCT ceiling
decoupler
32"-37"
3
MDJ700
3
3
3
5
2
2
40"-42"
3
MDJ700
3
3
3
5
2
2
50"
3
MDJ710
3
3
3
5
2
2
32"-37"
4
MDJ700
4
4
4
6
2
2
40"-42"
4
MDJ710
4
4
4
6
2
2
50"
4
MDJ720
4
4
4
6
2
2
CURVILINEAR
Display Size
Number of
displays
MDJ model
PLCM-2
display mount
PLP display adapter plate
(see MountFinder
TM
)
EXT or ADJ extension column
(connects PLCM-2 to ACC600)
ACC600 interface
bracket to MDJ mount
ADD support
extension column
DCT ceiling
decoupler
32"-37"
3
MDJ701
3
3
3
5
2
2
40"-42"
3
MDJ701
3
3
3
5
2
2
50"
3
MDJ711
3
3
3
5
2
2
32"-37"
4
MDJ701
4
4
4
6
2
2
40"-42"
4
MDJ711
4
4
4
6
2
2
50"
4
MDJ721
4
4
4
6
2
2
Multi-Display Mount
Model
Length
Ring Diameter
Pipe Diameter
Load Capacity
Ship Weight
MDJ700 (in-line)
120"
(3048mm)
NA
1.90" OD
1000lb
(453kg)
31lb
(14.1kg)
MDJ710 (in-line)
180"
(4572mm)
NA
1.90" OD
1200lb
(544kg)
45lb
(20.4kg)
MDJ720 (in-line)
240"
(6096mm)
NA
1.90" OD
1500lb
(680kg)
62lb
(28.1kg)
MDJ701 (curved)
120"
(3048mm)
NA
1.90" OD
1000lb
(453kg)
27lb
(12.2kg)
MDJ711 (curved)
180"
(4572mm)
NA
1.90" OD
1200lb
(544kg)
35lb
(15.9kg)
MDJ721 (curved)
240"
(6096mm)
NA
1.90" OD
1500lb
(680kg)
56lb
(25.4kg)
MDJ760 (circular)
NA
48"
(122cm)
1.90" OD
600lb
(272kg)
45lb
(20.4kg)
Screen Mount
Model
Ship Weight
PLCM-2
PLP display adapter required. See MountFinder
TM
to verify display compatibility.
7.5lb
(3.40kg)
Multi-Display Interface Bracket
Model
Description
Load Capacity
Ship Weight
ACC600
Interfaces between flat panel mount to MDJ mount,
and MDJ mount to ceiling support structure.
1200lb
(544kg)
3.8lb
(1.7kg)
Fixed or Adjustable Extension Columns
for Attaching Mount
Model
Drop Length*
EXT/AEC/ALU models
6"-12'
(152-3657mm)
Fixed or Adjustable Extension Columns
for Ceiling Decouplers
Model
Drop Length*
ADD models
12"-12'
(304-3657mm)
Ceiling Decoupler
Model
Ceiling type
Load Capacity
Ship Weight
DCS400
For structural or finished ceiling
1200lb
(544kg)
7.8lb
(3.5kg)
DCT300
For truss ceiling
1200lb
(544kg)
4.6lb
(2.1kg)
DCT500
For I-Beams
600lb
(272kg)
9.4lb
(4.3kg)
DCT600
For I-Beams
600lb
(272kg)
13.1lb
(6kg)
DCT700
For I-Beams
600lb
(272kg)
13.6lb
(6.2kg)
DCT800
For I-Beams
600lb
(272kg)
14lb
(6.4kg)
DCT900
For I-Beams
600lb
(272kg)
9lb
(4.1kg)
DCS400
DCT300
DCT500-900
See page 95 for details
CIRCULAR
Display Size
Number of
displays
MDJ model*
PLCM-2
display mount
PLP display adapter plate
(see MountFinder
TM
)
EXT or ADJ extension column
(connects PLCM-2 to ACC600)
ACC600 interface
bracket to MDJ mount
ADD* support
extension column
DCT ceiling
decoupler
32"-37"
3
MDJ760
3
3
3
3
1
1
40"-42"
3
MDJ760
3
3
3
3
1
1
50"
3
MDJ760
3
3
3
3
1
1
32"-37"
4
MDJ760
4
4
4
4
1
1
40"-42"
4
MDJ760
4
4
4
4
1
1
* Columns over 9' will be covered in vinyl
See page 193 for details
See page 194 for details
See page 191 for details
MULTI-DISPLAY SYSTEM COMPONENTS
* Fixed length columns provide 6" to 10' (152.4-3048mm) drop lengths.
Adjustable length columns provide 6" to 12' (152-3657mm) drop lengths.
* Fixed length columns provide 1' to10' (304-3048mm) drop lengths.
Adjustable length columns provide 1' to 12' (304-3657mm) drop lengths.
