Remove the valve body mounting hardware from the valve body.
Tightly screw in co-responding hoses (M) in the the valve body. (Blue hose for
cold, red hose for hot) For proper handle turning direction, install the handle with
the "Hot" red label on the left side. Slide the valve body's flexible hoses though the
counter top / sink mounting holes.
From beneath the counter top/sink, secure the valve body with gaskets (H), metal
washer (I) & locking nut (J).
To properly lock valve in place hand tighten locking nut (J) till snug then align
handle and use a screwdriver to lock nut in position.
Wrap threads with Tefon/Plumbers tape then loop, connect and tighten the flexible
hoses to the tee connector.
Wrap threads with Teflon/Plumbers tape around water inlets (K), then connect
corresponding hot and cold water lines and tighten water supply lines.
After all connections have been made, turn on water supply and check for leaks. If
water leaks from any connections tighten the connection till leakage stops.
If there are no leaks, unscrew aerator (L) and turn handles to flush any debris for 1
min. Replace aerator when done.
GENERAL INSTALLATION INSTRUCTION
Latitude2 Widespread faucet
2
L
K
H
I
J
HOT
M
