American Car Craft Camaro Engine Shroud Dress Up Kit 10Pc V6 ONLY 2010-2013 User Manual
American car craft instructions
AMERICAN CAR CRAFT INSTRUCTIONS
CAMARO V6 ENGINE SHROUD COVER
PART #103046
patent pending
Parts Included:
2-Brushed top plates
1-Center Top Plate
6-Gold Squares
1-3/4 Chrome cap
1-Promoter packet
1-promoter tube
1 abrasive scratch pad
Introduction: This new cover comes to you in several pieces that will beautifully set in position over the
factory V6 engine shroud. Each of the components is made of high quality stainless steel and stick in place via
3M Attachment tape making this installation very easy.
Liner Information: Your new accessories will come to you with a protective surface liner. Leave this liner in
place until the installation is complete to prevent finger prints and or possible scratches during installation.
1. The first step will be to thoroughly scrub the entire surface of the factory shroud with alcohol to remove any
and all dirt and grime. Once this is done place several strips of masking tape along the surface of the shroud to
see if you have achieved a tack. If the masking tape sticks to the surface then you will know that you have
cleaned it well. Swipe all the areas that will be mounted with the adhesive promoter packets supplied with
