100 mbps Ethernet media converter
iMcV-LIM with LFPT and Config Control
100 mbps Ethernet media converter
iMcV-LIM with LFPT and Config Control
Satisfying today’s networking needs while preparing for tomorrow’s
cabling requirements can make designing and installing the physical
layer of networks a daunting task. The decreasing cost of fiber optic
cabling and switching equipment makes all-optical LANs the obvious
choice when future-proofing network equipment. Replacing legacy
equipment and wiring infrastructure is a costly choice. Managed media
conversion allows implementation of new technologies on existing
networks, while monitoring all connections, to keep networks running
and up-to-date.
B&B Electronics offers a wide range of SNMP-managed Ethernet
copper to fiber media converters, with a choice of fixed rate or
rate conversion capabilities. The “iMcV-“ modules also include
troubleshooting features and LEDs to assist in network diagnostics as
well as make isolating cable breaks easier. The 100 Mbps iMcV-Lim
also features Link Fault Pass-Through. In addition, the modules provide
Configuration Control.
All converters feature an RJ-45 copper port and a fiber port, with a
choice of SC or ST connectors, and are hot-swappable.
product FEaturEs
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
iMcv-liM tx/Fx and tx/sx
850-15611 SX-MM850-ST
1 2 km 1 RJ45
850-15612 SX-MM850-SC 1 2 km 1 RJ45
850-15613 FX-MM1300-ST 1 5 km 1 RJ45
850-15614 FX-MM1300-SC 1 5 km 1 RJ45
850-15617 FX-SM1310/PLUS-ST 1 40 km 1 RJ45
850-15618 FX-SM1310/PLUS-SC 1 40 km 1 RJ45
850-15619 FX-SM1310/LONG-ST 1 80 km 1 RJ45
850-15620 FX-SM1310/LONG-SC 1 80 km 1 RJ45
850-15622 FX-SM1550/LONG-SC 1 80 km 1 RJ45
850-15623 FX-SM1550/XLONG-SC 1 100 km 1 RJ45
single strand FiBer *
850-15631 SSFX-MM1310-SC 1 2 km 1 RJ45
850-15632 SSFX-MM1550-SC 1 2 km 1 RJ45
850-15633 SSFX-SM1310-SC 1 20 km 1 RJ45
850-15634 SSFX-SM1550-SC 1 20 km 1 RJ45
850-15635 SSFX-SM1310/PLUS-SC 1 40 km 1 RJ45
850-15636 SSFX-SM1550/PLUS-SC 1 40 km 1 RJ45
850-15637 SSFX-SM1310/LONG-SC 1 60 km 1 RJ45
850-15638 SSFX-SM1550/LONG-SC 1 60 km 1 RJ45
iMcV-LIM also available in CWDM Fiber. Call for details.
* These products have single-strand fiber technology. Deploy in pairs or connect another compatible
B&B IMC LLC single-strand fiber product.
• Available for multi-mode or single-mode fiber
• Double fiber capacity with single-strand fiber versions
• Monitor links and receive vital traffic and health information and
notification should problems occur
• Modular, hot-swappable architecture reduces operational costs
associated with product installation, upgrades and maintenance
• SNMP Manageable
• Convert 100 Mbps Copper to 100 Mbps Fiber
• LFPT and Config Control
iView: Windows 2000/XP/Vista/Win7
iMcV-LIM with LFPT and Config Control_3713ds
