RANGE
OM2 Multimode Fiber: Up to 50m (330 ft)
OM3 Multimode Fiber: Up to 100m (330 ft) *
SPEEDS
USB 3.0: Up to 5Gbps
LEX
USB Connector: 1 x USB 3.0 Type B Locking Receptacle
Link Connectors: 2 x LC Connectors
Dimensions: 100mm x 76mm x 26mm (3.94" x 2.99" x 1.02")
Enclosure Material: Anodized Aluminum
REX
USB Connectors: 2 x USB 3.0 Type A Locking Receptacles
Link Connectors: 2 x LC Connectors
Dimensions: 100mm x 76mm x 26mm (3.94" x 2.99" x 1.02")
Enclosure Material: Anodized Aluminum
Available Current: 900mA for each USB Port
Power Supply: 100-240V AC Input, 5V DC Output, Locking
ENVIRONMENTAL
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -20°C to 70°C (-4°F to 170°F)
Operating Humidity: 20% to 80% relative humidity, non-condensing
Storage Humidity: 10% to 90% relative humidity, non-condensing
COMPLIANCE
EMC: FCC (Class B), CE (Class B)
Environmental: RoHS
Machine Vision: AIA USB3 Vision (upon standard release)
SUPPORT
Warranty: 2 years
ExtremeLink ™ 4500 Product Specifications
USB 3.0 Spectra ™ 3022 Specifications
Ordering Information
The USB 3.0 Spectra™ 3022 system includes a LEX, REX, USB 3.0 cable, Quick Start Guide, one international power adapter
with country specific power cord and two year warranty.
For more information, email [email protected] or call +1 604 638 3920.
PART # NAME DESCRIPTION
00-00327 USB 3.0 Spectra™ 3022 - NA 2-Port Fiber 100m USB 3.0 Extender System, 100-240V Power Adapter, Locking NA Power Cord
00-00328 USB 3.0 Spectra™ 3022 - EU 2-Port Fiber 100m USB 3.0 Extender System, 100-240V Power Adapter, Locking EU Power Cord
00-00329 USB 3.0 Spectra™ 3022 - UK 2-Port Fiber 100m USB 3.0 Extender System, 100-240V Power Adapter, Locking UK Power Cord
00-00330 USB 3.0 Spectra™ 3022 - AU 2-Port Fiber 100m USB 3.0 Extender System, 100-240V Power Adapter, Locking AU Power Cord
21-00071 5V 3A Locking Power Adapter 100-240V, 2.5mm (ID) locking plug, IEC320-C7/C8 2-pin
Specifications subject to change
without notification.
©2012
Icron Technologies Corp.
#90-01040-A01
Locking USB Receptacles
Locking Power Connector
Storage Cameras
OM2 50m 50m
OM3 50m 100m
*Achievable USB 3.0 Extension by
Multimode Fiber Class
