switching 10/100 and 10/100/1000 mbps
pc card Ethernet media converters
McPC MediaLinX Series
McPC MediaLinX Series Media Converters are ideal for Fiber-to-
the-Desktop (FTTD) applications and for companies with frequent
workstation moves and changes. Installing inside a PC or workstation,
and plugging into an adjacent network interface card (NIC), these
compact units eliminate the need to place Media Converters on top
of desks or computers, reducing clutter of cords and adapters at the
workspace.
the McPC Medialinx series includes:
• 10/100 Mbps Switching Ethernet (MediaLinX)
- A rate converter as well as a media converter, the McPC
MediaLinX converts 10 or 100 Mbps over copper to 100 Mbps
over fiber.
• 10/100/1000 Mbps Switching Ethernet (Giga-MediaLinX)
- A rate converter as well as a media converter, the McPC Giga-
MediaLinX converts 10, 100 or 1000 Mbps over copper to 1000
Mbps over fiber.
McPC converters accommodate crossover or pass through connections,
with AutoCross, a feature which automatically selects the correct
operating mode. Units also feature handy status LEDS to assist in
network diagnostics and troubleshooting.
product FEaturEs
* These products have single-strand fiber technology. Deploy in pairs or connect another compatible
B&B IMC LLC single-strand fiber product.
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
McPC Medialinx PCi
855-12731 MM850-SC
1 2 km 1 RJ45
855-12733 MM1300-SC 1 5 km 1 RJ45
855-12735 SM1310/PLUS-SC 1 40 km 1 RJ45
McPC Medialinx lowPCi
855-15733 MM1300-ST
1 5 km 1 RJ45
855-15735 SM1310/PLUS-SC 1 40 km 1 RJ45
• Easily installs inside a desktop PC
• No configuration required, connects to existing NIC card
• No drivers to install
• Available in PCI, ISA, or low profile PCI slot
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
McPC giga-Medialinx PCi
855-12920 MM850-SC
1 220/550 m 1 RJ45
855-12921 SM1300-SC 1 15 km 1 RJ45
855-12922 SM1310/PLUS-SC 1 40 km 1 RJ45
855-12924 SM1550/LONG-SC 1 80 km 1 RJ45
single-strand FiBer*
855-12927 SSLX-SM1310-SC 1 15 km 1 RJ45
855-12928 SSLX-SM1550-SC 1 15 km 1 RJ45
855-12929 SSLX-SM1310/
PLUS-SC
1 40 km 1 RJ45
855-12930 SSLX-SM1550/
PLUS-SC
1 40 km 1 RJ45
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
McPC giga-Medialinx lowPCi
855-15919 SFP
1 Various 1 RJ45
855-15920 MM850-SC 1 220/550 m 1 RJ45
855-15921 SM1310-SC 1 15 km 1 RJ45
* SFP Fiber sold separately
Tight Security: U.S. Joint
Forces Command
Industry: Security
Product: McPC TP-TX/FX Multi-Mode
Fiber Media Converter
www.bb-elec.com/
USJFC
Carrier data charges
may apply.
In thE FIEld
accEssorIEs
806-39230 - SATA Cable for McPC
McPC MediaLinX Series_3713ds
