10/100/1000 mbps poE switching

media converter

PoE Giga-McBasic LFPT

10/100/1000 mbps poE switching

media converter

PoE Giga-McBasic LFPT

The PoE Giga-McBasic LFPT are the perfect solutions for network
applications that require Power over Ethernet for locations inside
buildings where PoE is required to power an Ethernet device. Their
small, table-top design and durability make them perfect for installation
anywhere space is limited. Additionally, both units are manufactured
with an internal AC power supply. This feature significantly increases
reliability over products that use awkward, external AC/DC power
transformers.

The PoE Giga-McBasic LFPT unit comes with one SFP or fixed fiber
transceiver, one PoE/PSE 10/100/1000Base-T copper port that provides
15.4 Watts of power with data, and one 10/100/1000 Mbps copper
port to connect a non-PoE unit to the same fiber uplink. A Link
Fault Pass Through DIP Switch is available, to enable a link LED
troubleshooting feature.

As a fiber-fed media converter, it provides both power and data to a
remote device over standard CAT5, eliminating the need for additional
power to the remote device. The copper ports Auto Negotiate to the
connected device’s speed and duplex mode: 10 Mbps, 100 Mbps or
1000 Mbps, and HDX or FDX (including Flow Control). Additionally, both
models support jumbo frames up to 10240 bytes.

• Connects 10/100/1000 Mbps copper to 100 or 1000 Mbps fiber SFP

or 10/100/1000 Mbps or 1000 Mbps copper SFP

• Supports Jumbo Frames (up to 10240 bytes
• Rugged standalone metal enclosure with internal power supply
• Features configurable PoE reset on Fiber Loss of Signal (LOS)
• Supports LFPT, a diagnostic feature that can be enabled to assist the

end user in troubleshooting a failed segment

• Supports IEEE 802.3af PoE (15.4W)

product FEaturEs

ordErIng InFormatIon

Model

nuMBer

FiBer

FiBer

Ports range

ethernet

Ports

ethernet

ConneCtor

Poe giga-McBasic lFPt *
852-11811 SFP

1

Various

2

RJ45

852-11812 SX-MM850-SC

1

220/550 m 2

RJ45

852-11813 LX-MM1300-SC

1

2 km

2

RJ45

852-11814 LX-SM1310-SC

1

10 km

2

RJ45

852-11815 LX-SM1310/PLUS-SC

1

40 km

2

RJ45

852-11816 LX-SM1550/LONG-SC

1

80 km

2

RJ45

852-11817 LX-SM1550/XLONG-SC 1

100 km

2

RJ45

Poe giga-McBasic lFPt single-strand Fiber **
852-11820 SSLX-SM1310-SC

(1310 xmt/1550 rcv)

1

15 km

2

RJ45

852-11821 SSLX-SM1550-SC

(1550 xmt/1310 rcv)

1

15 km

2

RJ45

852-11822 SSBX-SM1310-SC

(1310 xmt/1490 rcv)

1

10 km

2

RJ45

852-11823 SSBX-SM1490-SC

(1490 xmt/1310 rcv)

1

10 km

2

RJ45

852-11824 SSLX-SM1310/PLUS-SC

(1310 xmt/1550 rcv)

1

40 km

2

RJ45

852-11825 SSLX-SM1550/PLUS-SC

(1550 xmt/1310 rcv)

1

40 km

2

RJ45

852-11826 SSBX-SM1490/PLUS-SC

(1490 xmt/1310 rcv)

1

30 km

2

RJ45

852-11827 SSBX-SM1310/PLUS-SC

(1310 xmt/1490 rcv)

1

30 km

2

RJ45

852-11828 SSLX-SM1490/LONG-SC

(1490 xmt/1550 rcv)

1

70 km

2

RJ45

852-11829 SSLX-SM1550/LONG-SC

(1550 xmt/1490 rcv)

1

70 km

2

RJ45

** These products have single-strand fiber technology. Deploy in pairs or connect another compatible

B&B IMC LLC single-strand fiber product.

* SFP Fiber sold separately

PoE Giga-McBasic LFPT also available in CWDM Fiber.

Call for details.

accEssorIEs

895-39226 - Rackmount Bracket
895-39227 - Wallmount Brackets
895-39949 - Rackmount Shelf
