Industrial grade radio modems
– up to 40mi/64km range
Zlinx Wireless Radio Modems
Model nuMBer:
ZP24d-250rM-Sr
ZP8d-24rM-lr
ZP9d-115rM-lr
rF ProPertieS
Standard
IEEE 802.15.4
Proprietary Radio
Proprietary Radio
Range(with included antenna)
up to 300ft/91m indoor
or 1mi/1.6km outdoor
Up to 24.9mi/40km outdoor
up to 3000ft/.91km indoor
or 14mi/22.5km outdoor
Frequency
2.4 GHz
868 MHz
900 MHz
Transmit Power
100mW
316mW
1W
SoFtware
Support
Win XP, Win 7
Features
RSSI signal range test Modem emulation
inCluded oMni antenna
2.1 dBi
3 dBi
3 dBi
antenna ConneCtor
External Reverse Polarity SMA male jack connector, omni directional (included with product)
Serial ProPertieS
Baud
1200, 2400, 4800, 9600,
19200, 38400, 57600,
115200
1200, 2400, 4800, 9600,
19200, 38400, 57600,
115200, 230400
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400
Data Bit; Parity; Stop Bit
8 only; none only; 1 only
7, 8; None, even, odd, mark,
space; 1, 2
7, 8; None, even, odd, mark, space; 1, 2
RS-232
DB9F DCE or Terminal Block (TX, RX, GND available on Terminal Block
RS-422
Removeable terminal block, 2 or 4 wire - TX+, TX-, RX+, RX-, GND, 120 Ohm Dipswitch selectable
RS-485
Removeable terminal block, 2 or 4 wire - TX+, TX-, RX+, RX-, GND, Bit wise, 120 Ohm Dipswitch selectable
wireleSS link Failure
Removeable terminal block, Open collector, dry contact, 40mA
Power
Power Supply
10-48 VDC, 18-30 VAC, Removeable terminal block
Power Consumption
2.0W max
6W max
5.0W max
diMenSionS
1.2W x 3.3D x 4.7H
enVironMental
Operating Temperature
-40° to 85ºC
Storage Temperature
-40° to 85ºC
Operating Humidity
10 to 90% non-condensing
enCloSure rating
Rating
IP30
Mounting
DIN rail mount, 35mm
LED Status
Power, Signal Strength, Wireless Data
CertiFiCationS
FCC
FCC Part 15 Class B
CE
CISPR (EN55022) Class B
EN61000-6-1 Generic Standards for Residential, Commercial, & Light Industrial
EN61000-4-2-ESD, EN61000-4-3 RFI, EN61000-4-4 EFT, EN61000-4-5 Surge, EN61000-4-6 CI, EN61000-4-8 Power Frequency
Magnetic, EN61000-4-11 Voltage Dips & Interruptions
UL
UL, cUL
UL, cUL
UL, cUL, Class 1 Div 2 Groups A, B, C, D File E245458
RoHS directive (lead free)
Yes
