BENEFITS
THE INDUSTRIAL NETWORK COMPANY
Industrial Media Converter
• Compact Size, Small Footprint
• Converts 10/100/1000BaseT to 1000BaseSX/LX
• High Reliability/Availability
• Extended Environmental Specifi cations
• Hardened Metal DIN-Rail Enclosure
• High Performance
• High MTBF >2M Hours (measured)
• ESD Protection Diodes on RJ-45 Ports
• Surge Protection Diodes on Power Inputs
Ease of Use
• Plug & Play Operation
• RJ-45 Auto Sensing 10/100/1000BaseT Port
• RJ-45 Port Auto Senses Duplex,Speed, and
Cable Type
• Compact DIN-Rail Package
Increased Performance
• Full Wire Speed Capable
• 1000BaseSX/LX Fiber Uplink
• Full Duplex Capable
• Eliminates Network Collisions
• Increases Network Determinism
Regulatory Approvals
FCC/CE (CFR 47, Part 15, Subpart B, Class A)
EN 61000-6-2/4, IEC 61000-4-2/3/4/5/6
EN 55011, ICES-003
UL/cUL: Class I, Division 2, Groups A, B, C and D; T4A
UL 508, ICE and ANSI/ISA-12.12.01-2007
ABS Type Approval for Shipboard Applications
DNV Type Approval Certifi cation
GOST-R Certifi ed, RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/TS2 for Traffi c Control
1002MC SPECIFICATIONS
Case Dimensions
Height: 4.3" (11.0 cm)
Width: 1.0" (2.6 cm)
Depth: 3.7 (9.4 cm)
Weight: 0.60 lbs. (0.22 kg)
DIN-Rail: 35mm
Electrical
Input Voltage: 10-30 VDC
Input Current: 200mA@24V
Inrush: 13Amp/0.8ms@24V
Environmental
Operating Temperature: -40 o C to 85 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Network Media
10BaseT: >Cat3 Cable
100BaseT: >Cat5 Cable
1000BaseT: >Cat5e Cable
1000BaseSX Multimode: 50-62.5/125μm
1000BaseLX Singlemode: 7-10/125μm
Connectors
10/100/1000BaseT: One (1) RJ-45 TX Port
1000BaseSX/LX SFP: One (1) SFP LC Duplex
Gigabit Fiber Port
Recommended Wiring Clearance
Front: 5" (12.70 cm)
Top: 1" (2.54 cm)
Ordering Information
1002MC-SX 1000BaseSX multimode fi ber
1002MC-LX-ZZ 1000BaseLX singlemode fi ber
1000-PM Panel Mount Kit
NTPS-24-1.3 DIN-Rail Power Supply
[email protected] Amp
Where "ZZ" is: 10 for 10km max. fi ber segment length
40 for 40km max. fi ber segment length
70 for 70km max. fi ber segment length
Fiber Length
550m for 50/125μm
275m for 62.5/125μm *
10km ** 40km ** 70km **
TX Power Min -9.5dBm -9.5dBm -2dBm 0dBm
RX Sensitivity Max -17dBm -20dBm -22dBm -23dBm
Wavelength 850nm 1310nm 1310nm 1550nm
Assumed Fiber Loss
3.5 to 3.75
dB/km
.45
dB/km
.35
dB/km
.25
dB/km
Laser Type VCSEL FP DFB DFB
SFP Gigabit Fiber Transceiver Characteristics
* SX Fiber Optic Cable
** LX Fiber Optic Cable
REV 090805
