Troubleshooting
Fast, Easy Answers...
Connecting a Signal Ground
(common, reference) on the RS-422/485 side. The specifications
for most RS-422 and RS-485 devices indicate that the device
can withstand a maximum VCM of -7 volts to +12 volts. The
function of the GND connection is to tie the signal grounds of
all nodes on a network to one common ground potential. This
ensures that the common mode voltage cannot exceed the
specified value.
A signal ground is required on the 485DRCI-PH because it is
an optically isolated device. If you do not have a signal ground
(common, reference) on your RS422/485 device, you can
connect to the DC power ground of your RS422/485 device.
Caution: Make sure that this is connected correctly.
Note: Do not use the shield drain wire as the
signal ground between RS-422/485 devices.
Information – UL Class 2 Div 2
1. Refer to the Nonincendive Field Wiring
Apparatus Control Drawing for important
information.
2. Power, Input / output (I/O) wiring
for the end use enclosure must be in
accordance with Class 1 Division 2 wiring
methods (Article 501.10(B) of the National
Electric Code, NFPA 70) and in accordance
with the local authority having jurisdiction.
3. Maximum ambient air temperature
85°C.
4. Temperature rating of field installed
conductors 105°C. Use Copper Wire Only.
5. These devices must be installed in end
use enclosure suitable for the location.
6. WARNING – EXPLOSION HAZARD
SUBSTITUTION OF COMPONENTS MAY
IMPAIR SUITABILITY FOR CLASS 1,
DIVISION 2.
7. WARNING – EXPLOSION HAZARD:
DO NOT DISCONNECT EQUIPMENT
UNLESS POWER HAS BEEN SWITCHED
OFF OR THE AREA IS KNOWN TO BE
NON-HAZARDOUS.
8. WARNING – THIS APPARATUS IS
SUITABLE FOR USE IN CLASS 1 DIVISION 2,
GROUPS A, B, C, AND D OR NONHAZARDOUS
LOCATIONS ONLY.
Fast and easy on the web:
www.bb-elec.com
Triple Isolated RS-232 to
RS-422/485 Converter
485DRCI-PH
Document number – pn8931_R003_485DRCI-PH_0113qsg
© 2013 B&B Electronics Manufacturing Company
1-888-948-2248 | Europe: +353 91 792444
www.bb-elec.com
Recommended Accessories
DRAD35
DIN Rail Adapter
Please double check
Step 2.
You can also use your
smart phone to access
complete documentation
on our website. Simply
scan code to the right.
485DRCI-PH
Additional Items Required but Not
Included:
First Things First...
Before you begin, be sure you have
the following:
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.bb-elec.com | E-mail: [email protected]
•
•
Q
uick
S
tart
G
uide
MDR-20-24
Power Supply
A 10 to 48 VDC Power Supply,.
(Converter draws 1.9 W Max.)
