Items Included

2

Hardware Installation

3

LED Chart

4

Ports

5

DIP Switch Settings

Quick Start Guide

ELinx EIS-G-SFP 1000Base-T to

Gigabit SFP Media Converter










o

Gigabit Media Converter

o

AC Power Adaptor

o

This Quick Start Guide

o

Rubber Feet

Note: A gigabit 1000Base-SX/LX SFP module is
required but not included.




1.

Apply Rubber feet to bottom of media
converter and select a suitable mounting
location. Can be wall mounted using slots on
the bottom of case.

2.

Do not locate in areas subject to high moisture
or potentially wet conditions. Locate where the
temperature range does not exceed 0 to 45°
C. Make sure unit receives adequate
ventilation.

3.

Insert 1000Base-SX/LX module into SFP
socket. Accepts 1000Base multi-mode or
single-mode fiber SFP modules.

4.

Connect AC power adaptor to Media
Converter and plug into wall outlet. Outlet
should be within 6 feet (1.8 meters).



5.

Insert RJ-45 Ethernet line into 1000Base-T
port first and then connect the fiber port. The
copper port auto detects duplex mode and
supports auto MDI/MDIX for uplink purposes.
Connected device must be gigabit capable
on the copper port to work with this media
converter.

6.

Can be installed in optional media converter
chassis system (EIS-RACK-16).









LEDs

State

Indication

Power

Steady

Power applied

Off

No power

LNKC

Steady

TX port: A valid network connection established

LNKC stands for LINK/Copper

Off

No connection

LNKF

Steady

FX port: A valid network connection established

LNKF stands for LINK/Fiber

Off

No connection

FDX/COL

Steady

Connection in full duplex mode

FDX stands for FULL DUPLEX

RX

Steady

Receiving data/Copper

Off

No reception

TX

Steady

Transmitting data/Copper

Off

No transmission












IMPORTANT: The copper port is 1000Base-T only and will only
connect to gigabit speed devices.
High quality Category 5e cable or better should be used.
1000BASE-T requires all four pairs to be present and is far less
tolerant of poorly installed wiring than 100BASE-TX systems.

The 1000Base-SX/LX SFP module socket for Gigabit optic
expansion.





This device is plug_and_play; however, the following DIP
switch selections are available.

Auto or Full Duplex (Left DIP Switch)
The default setting is auto detection in the up position. Force
the fiber port to full duplex mode when in down position.

Link-Fault-Pass-Through (Right DIP Switch)
The default setting is link-fault-pass-through disabled in the
up position. If not enabled and one side of the link fails, the
other side continues transmitting packets, and waits for a
response that never comes. When enabled, LFPT will force
the link to shut down as soon as it notices that the other link
has failed. This gives the application software a chance to
react to the situation.

DIP Switch

Top Left

Top Right

Up
(Default)

Auto duplex
mode

Link-Fault-Pass-Through
function Off

Down

Force full
duplex mode

Link-Fault-Pass-Through
function On

Note: DIP switch settings also shown on bottom of unit.
