716TX Specifi cations
Switch Properties
Number of MAC Addresses:
8000
Aging Time : Programmable
Latency Typical: 2.6 μs
Switching Method
: Store-and-Forward
Case Dimensions
Height:
2.3" (5.8 cm)
Width: 8.3" (21.0 cm)
Depth: 4.8" (12.1 cm)
Weight (max):
3.3 lbs (1.5 kg)
DIN-Rail Mount: 35mm
Electrical
Redundant Input Voltage:
10-30 VDC (Regulated)
Input Current (max): 620mA max. @ 24VDC
N-TRON Power Supply: NTPS-24-1.3 (1.3A
@
24V)
Environmental
Operating Temperature:
-40 o C to 70 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 95%
(Non Condensing)
Operating Altitude:
0 to 10,000 ft.
Shock and Vibration (bulkhead mounted)
Shock:
200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF:
>2 Million Hours
Network Media
10BaseT:
>Cat3 Cable
100BaseTX: >Cat5 Cable
Connectors
10/100BaseTX:
Sixteen (16) RJ-45 Copper Ports
Recommended Wiring Clearance
Front
: 4" (10.16 cm)
Side : 1" (2.54 cm)
Regulatory Approvals
FCC Title 47, Part 15, Subpart B - Class A; ICES-003 - Class A
UL Listed (US and Canada) 1604; ANSI/ISA-12.12.01-2007
Class I, Div 2, Groups A, B, C, D, and T4A
CE: EN61000-6-2:2001: EN61000-4-2, 3, 4, 5, 6
EN55011:1998+A1:1999+A2:2002-Class A
EN50155 for Railway applications
GOST-R Certifi ed, RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/ TS2 for Traffi c control
716TX Industrial Ethernet Switch Ordering Information
716TX Sixteen 10/100BaseTX Ports
700-PM Panel Mount kit
URMK Universal Rack Mount Kit
NTPS-24-1.3 N-TRON Power Supply - (1.3 Amp @ 24VDC)
