Control Series
The larger Control Series offers standard features as well as full-panel access and all usable
panel space. In addition, the standard grey cover is available with or without a full-length
polycarbonate viewing window. Other options include removable aluminum deadfront panel
and painted carbon steel and aluminum back panels.
Control Series enclosures insulate and protect controls and components against the toughest
elements in the harshest environments. Available in popular larger sizes and depths and with
standard stainless steel hinges and latches.
C o n t r o l S e r i e s F e a t u r e s
& B e n e f i t s
• Molded fiberglass reinforced polyester construction for durability
• One-piece body construction provides added
dimensional stability
• Standards sizes from 24" x 20" x 9-3/4" to 30" x 24" x 11-3/4"
• Closed-cell neoprene gasket encased in a continuous channel
• Raised cover for additional depth
• 304 stainless steel hardware and mounting feet
• Mounting panel inserts for optional back panel
• Optional hinged deadfront panel
• UV stabilized for outdoor use
