REV 101103
110FX2 Specifi cations
Switch Properties
Number of MAC Addresses: 8000
Latency Typical: 2.6 μs
Switching Method
: Store-and-Forward
Case Dimensions
Height:
4.3" (10.8 cm)
Width: 2.4" (6.1 cm)
Depth: 4.6" (11.5 cm)
Weight (max): 1.4 lbs (0.64 kg)
DIN-Rail Mount:
35mm
Electrical
Redundant Input Voltage: 10-49 VDC (Regulated)
Input Current (max): 355mA max@24VDC
BTU/hr: 29.1@24VDC
N-TRON Power Supply: NTPS-24-1.3 (1.3A@24V)
Environmental
Operating Temperature: -40 o C to 80 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounted)
Shock: 200g@10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF: >2 Million Hours
Network Media
10BaseT:
≥Cat3 Cable
100BaseTX: ≥Cat5 Cable
THE INDUSTRIAL NETWORK COMPANY
Connectors
10/100BaseTX: Eight (8) RJ-45 Copper Ports
100BaseFX: Two 100BaseFX Ports, ST or SC
Recommended Wiring Clearance
Front : 4" (10.2 cm)
Side
: 1" (2.6 cm)
Regulatory Approvals
• FCC: Title 47, Part 15, Subpart B, Class A; ANSI C63.4;
ICES-003
• UL /cUL: Class I, Div 2, Groups A, B, C, D and T4
• CE: IEC 61000-4-2/3/4/5/6/8/11, EN 61000-6-2/4
• GOST-R Certifi ed, RoHS Compliant
®2010 N-TRON, Corp. N-TRON and the N-TRON logo are trademarks of N-TRON, Corp. Product names mentioned herein are for identifi cation purposes only and may be trademarks
and/or registered trademarks of their respective company. Specifi cations subject to change without notice. The responsibility for the use and application of N-TRON products rests
with the end user. N-TRON makes no warranties as to the fi tness or suitability of any N-TRON product for any specifi c application. N-TRON
Corporation shall not be liable for any
damage resulting from the installation, use, or misuse of this product. Printed in USA.
Contact Information
N-TRON Corp. N-TRON Asia N-TRON Europe GmbH
820 S. University Blvd., Suite 4E Suite #: 2267, 22/F, One Lujiazui Alte Steinhauserstr 19
Mobile, AL 36609 USA 68 Yin Cheng Road Center, 6330 Cham / Zg Switzerland
TEL: (251) 342-2164 Pudong New Area TEL: +41 41 7406636
FAX: (251) 342-6353 200120 Shanghai, P.R. China FAX: +41 41 7406637
Website: www.N-TRON.com TEL: +86 (0) 21 6194 6777
Email: [email protected] FAX: +86 (0) 21 6194 6699
Fiber Transceiver Characteristics
Fiber Length 2km* 15km** 40km** 80km**
TX Power Min -19dBm -15dBm -5dBm -5dBm
RX Sensitivity Max -31dBm -31dBm -34dBm -34dBm
Wavelength 1310nm 1310nm 1310nm 1550nm
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
