ExtremeLink ™ 4500 Product Specifications
USB 1.1 Rover ® 1850 Specifications
Ordering Information
The USB 1.1 Rover® 1850 system includes a LEX, REX, Quick Start Guide and three year warranty.
For more information, email [email protected] or or call +1 604 638 3920.
PART # NAME DESCRIPTION
00-00301 USB 1.1 Rover® 1850 1-Port 85m Cat 5e bus-powered USB Extender System
Specifications subject to change
without notification.
©2013
Icron Technologies Corp.
#90-00874-A04
RANGE
Full-Speed and Low-Speed: Up to 40m (131 ft)
Low-Speed: Up to 85m (279 ft)*
LEX (LOCAL EXTENDER)
USB Connector: 1 x USB Type A Plug
Pig Tail Length: 45.7cm (18")
Link Connector: 1 x RJ45
Dimensions: 85mm x 40mm x 22mm (3.34" x 1.57" x 0.87")
Enclosure Material: Black ABS
REX (REMOTE EXTENDER)
USB Connector: 1 x USB Type A Receptacle
Pig Tail Length: 15.2cm (6")
Link Connector: 1 x RJ45
Maximum Current Available: 400mA when LEX is supplied with 700mA
Dimensions: 85mm x 40mm x 22mm (3.34" x 1.57" x 0.87")
Enclosure Material: Black ABS
ENVIRONMENTAL
Operating Temperature: 0°C to 50°C (32°F to 122°F)
COMPLIANCE
Emissions: FCC (Class A), CE (Class A)
Immunity: CE Criteria A
Environmental: RoHS2 (CE)
Safety: CPSIA, Flammability V-1
SUPPORT
Warranty: 3 years
* device and host dependant
