Specifications
Technology
Standards: IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3x, Ethernet over VDSL
Protocols: Transparent to higher layer protocols
Processing Type: IEEE802.3x Full-duplex flow control
Interface
Ethernet Port:
RJ-45, 10/100Base-TX Full/Half-duplex Auto-Negotiation, Auto-MDI/MDIX
Speed:
10/100Mbps
Distance:
328ft. (100meters)
Cable:
10Base-T: UTP CAT. 3, 4, 5 (2-pair wire), 100Base-TX: UTP CAT. 5 (2-pair wire)
Extender Line Port:
BNC Coaxial
Speed:
1/5/10/20/30/40/50/60/70/75Mbps
Distance:
8,530ft. (2,600meters)
Cable:
Coaxial Cable (5C2V / RG6AU)
Power
Environmental
Input Voltage:
12 to 48VDC (Terminal
Block); 12VDC (DC Jack)
Operating
Temperature:
-40°C to 75°C (-40°F to 167°F)
Power Consumption:
7.2W Max. 0.6A@12VDC,
0.15A@48VDC
Storage
Temperature:
-40°C to 85°C (-40°F to 185°F)
Overload Protection:
Present
Humidity:
5% to 95% (non-condensing)
Reverse Polarity Protection:
Present
MTBF:
265,154 hours
MTBF Calculation:
Parts count reliability prediction @ 25°C
Mechanical
Enclosure:
Aluminum case, IP30
Dimensions:
1.97" (W) x 4.33" (D) x 5.31" (H); 5.0cm (W) x 11.0cm (D) x 13.5cm (H)
Weight:
1.76 lbs., (800g)
Installation:
DIN-Rail (Top hat type 35mm), Panel Rack Mounting
Regulatory Approvals
RoHS - Yes
Safety:
UL508
EMI:
FCC Part 15, Class A
EN61000-6-4
EN55022, EN61000-3-2, EN61000-3-3
EMS:
EN61000-6-2
EN61000-4-2 (ESD Standards) Contact: + / - 4KV; Criteria B Air: + / - 8KV; Criteria B
EN61000-4-3 (Radiated RFI Standards) 10V/m, 80 to 1000MHz; 80% AM Criteria A
EN61000-4-4 (Burst Standards) Signal Ports: + / 4KV; Criteria B D.C. Power Ports: + / 4KV; Criteria B
EN61000-4-5 (Surge Standards) Signal Ports: + / - 2KV; Line-to-Line; Criteria B D.C. Power Ports: + / -
0.5KV; Line-to-earth; Criteria B
EN61000-4-6 (Induced RFI Standards) Signal Ports: 10Vrms @ 0.15~80MHz; 80% AM Criteria A D.C.
Power Ports: 10Vrms @ 0.15~80MHz; 80% AM Criteria A
EN61000-4-8 (Magnetic Field Standards) 30A/m @ 50, 60Hz; Criteria A
Environmental Test Compliance:
IEC60068-2-6 Fc (Vibration Resistance) 5g @ 10~150KHz, Amplitude 0.35mm (Operation/Storage/Transport)
IEC60068-2-27 Ea (Shock) 25g @ 11ms (Half-Sine Shock Pulse; Operation) 50g @ 11ms (Half-Sine Shock
Pulse; Storage/Transport)
IEC60068-2-32 Ed (Free Fall) 1M (3.281ft.)
