AMC will display the found Airborne device(s):
Connect Ethernet
Attach Antennas
Note: You may be required to wait up to 180 seconds
before the device is discovered and displayed.
Connect the antennas to the connectors on the sides of the
device.
LAN
Port
Front View
Serial Ports
Port View
Connect to the Device
Product Overview
Detachable
Terminal Block
Power
Port
install it from the B&B website. Just search for the model
number and follow the links to download software from
the Downloads section of the product page.
When AMC starts, it will request a login:
Manage Your Device
4
Right click the device’s name. Under “Connectivity Tools”
choose “launch Web browser for OEM-Cfg1.” This will
open the device’s browser-based management window.
Login to web interface:
Username “dpac”
Password: “dpac”
LEDs Antenna Port
Antenna
Connect a CAT5 Ethernet cable between the device and
an Ethernet port on a host computer.
Connect Power Supply
Connect the 5-36 VDC terminal block attachment or use
the AC power supply (optional). Alternatively, the Q5xx8
models support PoE and can be powered by a PSE
device supporting 802.3af, Class 1.
Run the Airborne Management Center (AMC)
application. If you don’t currently have AMC installed,
you can install it from the included CD or download and
Select Group Name: ‘manuf’ and enter Group Password:
“dpac”.
AMC will load and discover the attached device:
5
Configure Your Device
AMC will ask if you want to manage the new device,
select ‘Yes’:
Select ‘Yes’ to indicate device is using Factory Default
settings:
6
Continue configuration via the Web interface, start with
the Configuration -> Express Setup page.
Continued on the next page...
