3
Connecting the IE-iMcV-MuxDemux/4
Ports 1-4 The IE-iMcV-MuxDemux/4 allows 4 devices of differing wavelengths,
transmits the wavelengths along a single fiber, then separates the
wavelengths, enabling the fiber optic receivers to receive a signal of
the correct wavelength.
Port 5 Port 5 is an expansion port to allow multiple IE-iMcV-MuxDemux/4
to be daisy chained, or to carry a legacy 1310nm SM fiber link.
Port 5
Network
Port
This port allows two IE-iMcV-MuxDemux/4 to be connected back to
back there are no diagnostic LEDs for the IE-iMcV-MuxDemux/4.
