Troubleshooting
Are My Devices Wired As DTE or DCE?
How to Check:
1. Use Rule of Thumb - If the device plugs into
the computer serial port and works normally,
the device is wired as DCE (or the connection cable
is a crossover type that makes it work as a DCE).
If the device connects to the computer port using
a “null modem” crossover cable, it is wired as DTE.
2. Use RS-232 Line Tester - A quick and easy way
to determine the DTE/DCE port type is to use
a RS-232 line tester such as the 9PMTT. The tester
can show the signal state of any active RS-232
data lines using LEDs lighting Red or Green.
Active data lines are output from a device.
They may be either High or Low.
Information – UL Class 1 Div 2
1. Power, Input/Output (I/O) wiring for the end use
enclosure must be in accordance with Class 1,
Division 2 wiring methods (Article 501.10(B)
of the National Electric Code, NFPA 70)
and in accordance with the local authority
having jurisdiction.
2. The temperature rating of field-installed conductors
is 105°C. Use copper wire only.
3. Maximum ambient air temperature is 85°C.
4. These devices must be installed in end use enclosures
suitable for the location.
5. WARNING – EXPLOSION HAZARD: Substitution
of any components may impair suitability for Class 1,
Division 2.
6. WARNING – EXPLOSION HAZARD: Do not
disconnect equipment unless power has been
switched off or the area is known to be
non-hazardous.
7. WARNING – This device is suitable for use
in Class 1, Division 2, Groups A, B, C, and D
or in non-hazardous locations only.
Document number – p/n 8514 r002 232OPDRi-PH - 0812
© 2012 B&B Electronics Manufacturing Company
1-888-948-2248 | Europe: +353 91 792444
www.bb-elec.com
Recommended Accessories
and Power Supplies
Surge Protector
Industrial Power Supply
232HESP
MDR-20-24
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.bb-elec.com | E-mail: [email protected]
http://www.bb-elec.com/232OPDRI-PH
Fast and easy on the web: www.bb-elec.com
ILinx 232OPDR-PH RS-232I Isolated Repeater
Additional items required but not included:
(1) 10 to 48 VDC Power Supply
Two RS-232 Cables
Ground Cable
First Things First...
Before you begin, be sure you have
the following:
RS-232 Repeater with Triple Isolation
232OPDRI-PH
http://www.bb-elec.com/232OPDRI-
PH/ACC
http://www.bb-elec.com/232OPDRI-
PH/ACC
Fast, Easy Answers
• First, check step 2.
• Then use your smart
phone to access complete
documentation on our
web site. Simply scan
the code to the right.
