1000 mbps compact media converter
McBasic Gigabit (LFPT)
The McBasic’s small, table-top design and durability make it perfect
for installation anywhere space is limited. Additionally, the McBasic
comes with an internal AC power supply. This feature significantly
increases reliability over products that use bulky, external AC/DC power
transformers.
LinkLoss, FiberAlert and Link Fault Pass Through (LFPT) that make
isolating fiber breaks easier should they occur. The McBasic also
features AutoCross to support crossover/pass-through on the twisted
pair connection and diagnostic LEDs. Most McBasic units are available
with single-strand fiber which can effectively double the capacity of
fiber by allowing two individual channels to share one strand of fiber;
Full-Duplex data travels on different wavelengths — 1310 nm and
1550 nm, for example.
• Has a small, rugged design offering many advanced features
• Available for multi-mode or single-mode fiber
• LinkLoss, FiberAlert, and Link Fault Pass Through features,
along with LEDs, assist in diagnosing problems on fiber optic networks
• Convert 1000 Mbps twisted pair to 1000 Mbps fiber
product FEaturEs
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
McBasic gigabit (lFPt)
855-11913 SX-MM850-SC
1
220/550 m 1
RJ45
855-11914 LX-SM1310-SC
1
15 km
1
RJ45
855-11915 LX-SM1310/PLUS-SC 1
40 km
1
RJ45
855-11917 LX-SM1550/LONG-SC 1
80 km
1
RJ45
855-11918 LX-SM1550/XLONG-
SC
1
100 km
1
RJ45
single-strand FiBer *
855-11844 SSLX-SM1310-SC
1
15 km
1
RJ45
855-11845 SSLX-SM1550-SC
1
15 km
1
RJ45
855-11824 SSBX-SM1310-SC
1
10 km
1
RJ45
855-11825 SSBX-SM1490-SC
1
10 km
1
RJ45
855-11846 SSLX-SM1310/
PLUS-SC
1
40 km
1
RJ45
855-11847 SSLX-SM1550/
PLUS-SC
1
40 km
1
RJ45
855-11826 SSBX-SM1310/
PLUS-SC
1
30 km
1
RJ45
855-11827 SSBX-SM1491/
PLUS-SC
1
30 km
1
RJ45
855-11850 SSLX-SM1490/
LONG-SC
1
70 km
1
RJ45
855-11851 SSLX-SM1550/
LONG-SC
1
70 km
1
RJ45
855-11852 SSLX-SM1490/
XLONG-SC
1
80 km
1
RJ45
855-11853 SSLX-SM1550/
XLONG-SC
1
80 km
1
RJ45
* These products have single-strand fiber technology. Deploy in pairs or connect another compatible
B&B IMC LLC single-strand fiber product.
accEssorIEs
895-39226 - Rackmount Bracket
895-39949 - Rackmount Shelf
