Ethernet-based, modular media
converters chassis
MediaConverter/1
SpecificationS
Technical
Single slot AC chassis to house the following modules: McPIM, McLIM, McLIM
10/100 and McGigabit
Mechanical
Dimensions
1.64”H x 4.75”W x 5.5”D
(4.16cm H x 12.06cm W x 13.97cm D)
Shipping Weight 2 lbs (.9 kg)
Power
115/230 or 120-240 VAC, 50/60Hz, 0.3A/0.15A
(dimensions in inches)
EnvironmEntal
Operating Temperature:
DC Terminal Block
+32° to +122° F (0° to +50° C)
Storage Temperature: 13° to +158° F (-25° to +70° C)
Operating Humidity
5% to 95% (non-condensing),
0 – 10,000 ft. altitude
rEgulatory approvals
FCC Class A, UL/CUL, CE, CSA
mEchanIcal dIagram
4.75
2.32
.60
1.20
1.01
.07
1.64
5.50
