Ordering Information
306TX Six 10/100BaseTX Ports
306TX-N with N-View Firmware Option
THE INDUSTRIAL NETWORK COMPANY
REV 090804
® 2009 N-TRON, Corp., N-TRON and the N-TRON logo are trademarks of N-TRON, Corp. Product names mentioned herein are for identifi cation purposes only and
may be trademarks and/or registered trademarks of their respective company. Specifi cations subject to change without notice.
The responsibility for the use and application
of N-TRON products rests with the end user. N-TRON makes no warranties as to the fi tness or suitability of any N-TRON product for any specifi c application. N-TRON Corporation
shall not be liable for any damage resulting from the installation, use, or misuse of this product.
Printed in USA.
Contact Information
N-TRON Corp. N-TRON Europe GmbH
820 S. University Blvd., Suite 4E Alte Steinhauserstr 19
Mobile, AL36609USA 6330 Cham / Zg Switzerland
TEL: (251) 342-2164 TEL: +41 41 7406636
FAX: (251) 342-6353 FAX: +41 41 7406637
Website: www.n-tron.com
Email: [email protected]
306TX SPECIFICATIONS
Case Dimensions
Height: 3.1" (7.8 cm)
Width: 2.0" (5.1 cm)
Depth: 3.4" (8.6 cm)
Weight: 0.75 lbs (0.3 kg)
Electrical
Input Voltage: 10-30 VDC
Input Current: 250 mA@24V
Inrush: 8.0Amp/0.6ms@24V
Environmental
Operating Temperature: -20 o C to 70 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounting)
Shock: 200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Network Media
10BaseT: >Cat3 Cable
100BaseTX: >Cat5 Cable
Connectors
10/100BaseTX: Six (6) RJ-45 TX Ports
Recommended Wiring Clearance
Front: 4" (10.16 cm)
Top: 1" (2.54 cm)
Regulatory Approvals
FCC Part 15 Class A
UL Listed 1604 (US and Canada)
CLASS I, DIV 2, GROUPS A,B,C,D,T4A;
CE:EN61000-6-2,4
EN61000-4-2,3,4,5,6;
EN55011
ABS Type Approval for Shipboard Applications
GOST-R Certifi ed
RoHS Compliant
BENEFITS
Industrial Network Switch
• Compact Size, Small Footprint
• High
Reliability/Availability
• Extended Environmental Specifi cations
• Ruggedized DIN-RAIL Enclosure
• High
Performance
• High MTBF >2M Hours (measured)
Ease of Use
• Plug & Play Operation
• 6 Auto Sensing 10/100BaseTX RJ-45 Ports
• Auto Sensing Duplex, Speed, and Cable Type
• Unmanaged
Operation
• Compact DIN-RAIL Package
Increased Performance
• Full Wire Speed Capable
• Full Duplex Capable
• Eliminates Network Collisions
• Increases Network Determinism
• N-View Switch Viewing Option
