Applications
Ordering Information
The USB Ranger ® 2201 system includes a Local Extender (LEX) module, a Remote Extender (REX)
module, a 2 meter USB cable, and an International power adapter with country specific cord.
Name Part Number Description
USB Ranger ® 2201 00-00297
1-Port Cat 5 USB 2.0 Extender, International (100-240V)
Power Adapter: North American plug
USB Ranger ® 2201 00-00298
1-Port Cat 5 USB 2.0 Extender, International (100-240V)
Power Adapter: European plug
USB Ranger ® 2201 00-00299
1-Port Cat 5 USB 2.0 Extender, International (100-240V)
Power Adapter: UK plug
USB Ranger ® 2201 00-00300
1-Port Cat 5 USB 2.0 Extender, International (100-240V)
Power Adapter: Australian plug
Product Specifications
Range 100m (330 ft) over Cat 5e (or better) cable
LEX unit USB connector 1 x USB Type B
LEX unit Link connector 1 x RJ45
REX unit Link connector 1 x RJ45
REX unit USB connector 1 x USB Type A
Maximum USB devices supported 14 USB devices or 3 USB hubs with 11 USB devices
Power adapter Maximum Rating 5V DC @ 3A
Current available to USB at REX 1 x 500mA
LEX and REX unit dimensions 3.94” x 2.99” x 1.02” (100 mm x 76 mm x 26 mm)
Operating temperature range 0°C to 50°C
Total system shipping weight 2.0 lbs. (0.9 kilograms)
Regulatory testing FCC (Class B), IC (Class B), CE (Class B)
ESD Rating EMC EN-61000-4-2:2001 8kV Contact, 16kV Air
Specifications subject to change without notification.
Contact [email protected] for more information or OEM options.
4664 Lougheed Highway, Suite 221, Burnaby, BC V5C 5T5
T: 604-638-3920 F: 604-638-3930 [email protected]
©2011 Icron Technologies
Corporation US Patents
6,381,666 B1 & 7,149,833
Document #90-00856-A01
USB Ranger ® 2201
www.icron.com
• Industrial Control • KVM Extension
• Digital Signage • Remote Desktop USB Connections
• Home Network Integration • Security: web camera, access control.
• Medical Device Connectivity • USB Device Sharing: print, scan, storage.
