EIR508-xxx-x 1713ds - 1/2

© 2008 by B&B Electronics. All rights reserved.


Model: EIR508 Series

Eight Port Managed Industrial Ethernet Switches



Features

X-Ring Automatic Recovery

Dual 12 to 48 VDC Power Inputs

Relay Alarm Output

IP30 DIN Rail or Panel Mount

Wide Operating Temperature

Automatic E-mail Notification for system events

SNMP or Web GUI Management

Functional Description

The Elinx EIR508 series of Industrial Managed Ethernet Switches provide powerful functionality in a small
package. Designed for industrial applications, these switches contain all the standard features of other
switches, such at IGMP Snooping, Port Based VLAN, 802.1Q Tag VLAN, RJ-45 automatic MDI/MDI-X, auto
negotiation, store and forward switching, STP, RSTP, Web Based Management, Ingress Packet Filtering,
and Egress Rate Control. These managed switches also come with important industrial features to ensure
reliability in an industrial application. X-Ring technology with coupling ring and dual homing allows
automatic recovery in less than 300 MS. Dual power inputs ensure reliability. A relay alarm output for port
failure notification. DIN Rail and Panel Mounting options on the same IP30 case. Another important feature
is automatic e-mail notification for system events such as a cold start, change in network topology, power
status or SNMP authentication failure.

Ordering Information

Model Number

Description

EIR508-T

Industrial Managed Ethernet Switch, 8 10/100 RJ-45 Ports

EIR508-2MC-T

Industrial Managed Ethernet Switch, 6 10/100 RJ-45 Ports, 2 MM FO (SC) Port

EIR508-2MT-T

Industrial Managed Ethernet Switch, 6 10/100 RJ-45 Ports, 2 MM FO (ST) Port

EIR508-2SC-T

Industrial Managed Ethernet Switch, 6 10/100 RJ-45 Ports, 2 SM FO (SC) Port (30 KM)
