714FX6 Specifi cations
Switch Properties
Number of MAC Addresses:
8000
Aging Time : Programmable
Latency Typical: 2.6 μs
Switching Method : Store-and-Forward
Case Dimensions
Height:
4.3" (10.8 cm)
Width: 3.1" (7.9 cm)
Depth: 4.6" (11.5 cm)
Weight (max): 1.8lbs (0.8 kg)
DIN-Rail Mount: 35mm
Electrical
Redundant Input Voltage:
10-49 VDC (Regulated)
Input Current (max): 690mA max.@24VDC
N-TRON Power Supply: NTPS-24-1.3 (1.3A@24V)
Environmental
Operating Temperature:
-40 o C to 70 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounted)
Shock:
200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF:
>2 Million Hours
Network Media
10BaseT:
>Cat3 Cable
100BaseTX: >Cat5 Cable
714FX6 Industrial Ethernet Switch Ordering Information
714FX6-XX Eight 10/100BaseTX Ports, Six Multimode100BaseFX Fiber Optic Ports
714FXE6-XX-YY Eight 10/100BaseTX Ports, Six Singlemode100BaseFX Fiber Optic Ports
NTCD128 Optional confi guration card for backup / restore
NTPS-24-1.3 N-TRON Power Supply - (1.3 Amp @ 24VDC)
CPMA-2 Compact panel mount (factory installed option only)
URMK Universal Rack Mount Kit
Where: XX = ST or SC
YY = 15, 40, or 80 for Singlemode, Blank for Multimode
E = Singlemode, and Blank Otherwise
THE INDUSTRIAL NETWORK COMPANY
Contact Information
N-TRON Corp. N-TRON Asia N-TRON Europe GmbH
820 S. University Blvd., Suite 4E Unit 1209, Level 12 Alte Steinhauserstr 19
Mobile, AL 36609 USA Chong Hing Finance Center 6330 Cham / Zg Switzerland
TEL: (251) 342-2164 288 Nanjing Road West TEL: +41 41 7406636
FAX: (251) 342-6353 200003 Shanghai FAX: +41 41 7406637
Website: www.n-tron.com P.R. China
Email: [email protected] TEL: +86-021-6133-7770
FAX: +86-021-6133-7999
Connectors
10/100BaseTX:
Eight (8) RJ-45 Copper Ports
100BaseFX: Six (6) SC or ST Fiber Duplex Ports
Recommended Wiring Clearance
Front
: 4" (10.16 cm)
Side : 1" (2.54 cm)
Regulatory Approvals
FCC: Title 47, Part 15, Subpart B, Class A; ICES-003: Class A;
ANSI C63.4
CE: EN 61000-6-2, 4; IEC 61000-4-2, 3, 4, 5, 6, 8, 11
GOST-R Certifi ed, RoHS Compliant
CURRENTLY IN STANDARDS TESTING FOR:
UL/cUL: Hazardous Locations Class I, Div 2, Groups A, B, C, D, T4A
Non-hazardous Locations NASI/ISA 12.12.01-2007
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/ TS2 for Traffi c control
IEC-61850
100 Mb Fiber Transceiver Characteristics
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
Fiber Length 2km* 15km** 40km** 80km**
TX Power Min -19dBm/-14dBm -15dBm/-7dBm -5dBm/0dBm -5dBm/0dBm
RX Sensitivity Max -32dBm -34dBm -34dBm -34dBm
Wavelength 1310nm 1310nm 1310nm 1550nm
