System Connection Inc.
MODEL NO.
DESCRIPTION
DAVID NO.
ISSUE DATE
DP48-1201000
AC ADAPTOR
C169-75
2010/04/08
Page : 5
NO
DESCRIPTION
MATERIAL
SPEC & Q’TY
MANUFACTURER
01
Core
Silicon Steel
ν H50
SHEN ZHEN CHUN YUAN STEEL INC
(CERTIFICATE No.: 99PC 100616)
OR EQUIVALENT
02
Bobbin
N66
1 PCS.
SON KON Plastic & METAL MANUFAC
TURIN OR EQUIVALENT.
03
Enclosure
ABS or PPO
1 SET.
As Item 2.
04
Nameplate
PVC (UL/CSA)
0.27mm Thick
1 PCS.
Chi Yang Printing Mtg. OR EQUIV.
05
Output Cord
UL2468(UL/CSA) AWG22
Plug: S&T 10mm
1 PCS.
TAHENGELECTRONICSWIRE&CABLE
CO.,LTD.(E50032)OREQUIVALENT
06
Strain Relief
PVC.
1 PCS.
As Item 5.
07
Blade
Nickel plating Copper
1.45mm Thick
1 PCS.
As Item 1.
08
Thermal Cutoff Fuse.
130℃ 250V 2A
1 PCS.
JOINT FORCE METAL RESEARCH &
Co., LTD. (E142267) OR EQUIVALENT
09
The Primary Winding
Polyurethane Enameled
Copper Wire
FENG CHING METAL CORP.
(E172395) OR EQUIVALENT
10
The Primary Insulation.
Polyester Tape.
Press Board
0.05mm 2 Turns.
KA SHING ENTERPRISE Co., LTD.
OR EQUIVALENT
11
The Secondary Winding
Polyurethane Enameled
Copper Wire.
As Item 9.
12
The Secondary Insulation
Polyester Tape.
0.05mm 2 Turns.
0.25mm 1 PCS.
As Item 10.
13
Rectifier Board.
P.C.B (94V-0)
1 PCS
HUA SHENG ELECTRONICS Co., LTD.
OR EQUIVALENT
14
Diode
1N5391
4 PCS.
BYTESONIC CORPORATION
OR EQUIVALENT
15
Capacitor.
2200μF/25V 85℃
1 PCS.
TAY JYE ELECTRUNICS FACTORYOR
EQUIVALENT
DRAWING NAME
CROSS-SECTION
441 EAST BAY BLVD. PROVO, UT 84606 USA
DRAWING NO.
UNIT
mm
DRAWING NAME
