10 Port Industrial ethernet switch,
with gB, 2 rJ-45/sFP Ports
EIR410-2SFP-T
10 Port Industrial ethernet switch,
with gB, 2 rJ-45/sFP Ports
EIR410-2SFP-T
The EIR410-2SFP-T is a 10 Port Unmanaged Industrial Gigabit Ethernet
Switch. In addition to 8 standard copper RJ-45 ports, it has 2 CU/SFP
Combo slots to accommodate Gigabit Fiber.
small Form-factor Pluggable (sFP) Port: The SFP Port provides
flexibility when planning a network. The slot can accept any SFP fiber
module. Modules are available in multiple formats. If an SFP module is
not inserted, the associated combo port can be used with standard RJ-45
copper.
high-speed transmissions: The EIR410-2SFP-T includes a switch
controller that automatically senses transmission speed (10/100/1000
Mbps). The RJ-45 interface also auto-detects MDI or MDI-X, eliminating
the requirement for a crossover cable. Each port is buffered and supports
store-and-forward protocol.
dual Power input: To reduce the risk of power failure, the EIR410-2SFP-T
provides two 12 to 48 VDC power inputs. If the power fails, the switch will
automatically use the secondary power input. Also, if the power goes out
the corresponding P1 or P2 LED will go out and the Fault LED will light.
The contacts for the alarm output will also open.
Flexible Mounting: The switch features an IP30 metal enclosure that can
be DIN or Panel mounted.
transient Protection: The power input on the EIR410-2SFP-T offers
protection up to 3,000 V EFT. The Ethernet ports offer up to 6,000 V ESD
protection. These features make the switch reliable and suitable for use in
harsh electrical environments.
wide operating temperature: With an operating temperature of -40
to 75°C (-40 to 167°F), this switch is suitable for use in some of the
harshest industrial environments that exist.
easy troubleshooting: There are two LED indicators for each port that
display the link status and transmission speed. Three LED indicators
for power (P1, P2 and Fault) show power status. These indicators allow
you to quickly diagnose and correct problems and ensure your network
remains reliable.
• 8 10/100 Base-T Ethernet ports
• 2 RJ-45/SFP combo ports for Gigabit Ethernet
• 3000V EFT & 6000V ESD protection
• Dual 12 to 48 VDC power inputs
• Wide operating temperature
• DIN Rail or Panel Mount
Product FeAtures
AccessorIes
MDR-60-48 - DIN Rail Power supply 48VDC, 60W
C5UMB3FBL - 3 ft. (1 M) - Blue - Category 5e UTP Patch Cord
DFMM-LCLC-1M - Multi-Mode Duplex Fiber Cable, LC To LC, 1 Meter
DFSM-LCLC-1M - Single-Mode Duplex Fiber Cable, LC To LC, 1 Meter
SFP-1000SX-M-550M-T - SFP Module, 1000Base-SX, Multi-mode 550m, LC
Connector (-40 to 85°C)
SFP-100FX-M-2KM-T - SFP Module, 100Base-FX, Multi-mode 2km, LC Connector
(-40 to 85°C)
SFP-1000LX-S-10KM-T - SFP Module, 1000Base-LX, Single-mode 10km, LC
Connector (-40 to 85°C)
SFP-1000LX-S-20KM-T
- SFP Module, 1000Base-LX, Single-mode 20km, LC
Connector (-40 to 85°C)
SFP-100FX-S-30KM-T - SFP Module, 100Base-FX, Single-mode 30km, LC
Connector (-40 to 85°C)
orderIng InFormAtIon
Model nuMBer descriPtion
EIR410-2SFP-T Industrial Gigabit Switch (8 CU, 2 CU/SFP)
