7010TX Specifi cations
Switch Properties
Number of MAC Addresses: 8000
Aging Time: Programmable
Latency Typical: 2.6 μs
Switching Method: Store-and-Forward
Case Dimensions
Height: 4.3" (11 cm)
Width: 2.4" (6.1 cm)
Depth: 4.6" (11.5 cm)
Weight (max): TBD
DIN-Rail Mount: 35mm
Electrical
Redundant Input Voltage: 10-49 VDC (Regulated)
Input Current (max): 400mA max.@24VDC
N-TRON Power Supply: NTPS-24-1.3 (1.3A@24V)
Environmental
Operating Temperature: -40 o C to 70 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounted)
Shock: 200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF: >2 Million Hours
Network Media
10BaseT: >Cat3 Cable
100BaseTX: >Cat5 Cable
1000BaseTX: >Cat5e Cable
7010TX Industrial Ethernet Switch Ordering Information
7010TX Eight 10/100BaseTX Ports, Two Optional Gigabit SFP Ports
NTSFP-TX Optional SFP (Mini-GBIC) Transceiver with One 1000BaseT GB Copper Port
NTSFP-SX Optional SFP (Mini-GBIC) Transceiver with One 1000BaseSX Multimode GB Fiber Optic Port
NTSFP-LX-ZZ Optional SFP (Mini-GBIC) Transceiver with One 1000BaseLX Singlemode GB Fiber Optic Port
NTCD128 Optional confi guration card for backup / restore
NTPS-24-1.3 N-TRON Power Supply - (1.3 Amp @ 24VDC)
CPMA-1 Compact Panel Mount (factory installed option)
URMK Universal Rack Mount Kit
Where: ZZ = 10, 40, or 70 for GB Singlemode
If SFP Transceiver is not specifi ed at the time of purchase, slots will remain blank with covers
THE INDUSTRIAL NETWORK COMPANY
Contact Information
N-TRON Corp. N-TRON Asia N-TRON Europe GmbH
820 S. University Blvd., Suite 4E Unit 1209, Level 12 Alte Steinhauserstr 19
Mobile, AL 36609 USA Chong Hing Finance Center 6330 Cham / Zg Switzerland
TEL: (251) 342-2164 288 Nanjing Road West TEL: +41 41 7406636
FAX: (251) 342-6353 200003 Shanghai FAX: +41 41 7406637
Website: www.n-tron.com P.R. China
Email: [email protected] TEL: +86-021-6133-7770
FAX: +86-021-6133-7999
Connectors
10/100BaseTX:
Eight (8) RJ-45 Copper Ports
1000BaseSX: Up to Two (2) LC Duplex Gigabit
Fiber Ports (optional)
Recommended Wiring Clearance
Front: 4" (10.2 cm)
Side: 1" (2.6 cm)
Regulatory Approvals
FCC Title 47, Part 15, Subpart B - Class A; ICES-003 - Class A
GOST-R Certifi ed, RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/ TS2 for Traffi c control
IEC-61850
SFP Gigabit Fiber Transceiver Characteristics
* SX Fiber Optic Cable
** LX Fiber Optic Cable
Fiber Length 550m for 50/125μm 10km** 40km** 70km**
TX Power Min -9.5dBm/-4dBm -9.5dBm/-3.5dBm -2dBm/3dBm 0dBm/5dBm
RX Sensitivity Max -17dBm -20dBm -22dBm -23dBm
Wavelength 850nm 1310nm 1310nm 1550nm
Assumed Fiber Loss .45dB/km .35dB/km .25dB/km
Laser Type VCSEL FP DFB DFB
