THE INDUSTRIAL NETWORK COMPANY
BENEFITS
Industrial Media Converter
• Compact Size, Small Footprint
• Converts 10/100BaseTX to 100BaseFX
• High
Reliability/Availability
• Extended Environmental Specifi cations
• Hardened Metal DIN-Rail Enclosure
• High
Performance
• High MTBF >2M Hours (measured)
• ESD Protection Diodes on RJ-45 Ports
• Surge Protection Diodes on Power Inputs
Ease of Use
• Plug & Play Operation
• RJ-45 Auto Sensing 10/100BaseTX Port
• RJ-45 Port Auto Senses Duplex,
Speed, and Cable Type
• Compact DIN-Rail Package
Increased Performance
• Full Wire Speed Capable
• 100BaseFX Fiber Uplink
• Full Duplex Capable
• Eliminates Network Collisions
• Increases Network Determinism
102MC SPECIFICATIONS
Case Dimensions
Height: 2.9"
(7.4
cm)
Width: 1.5"
(3.9
cm)
Depth
3.6"
(12.3 cm)
Weight:
0.5 lbs. (0.22 kg)
DIN-Rail: 35mm
Electrical
Input Voltage:
10-30 VDC
Input Current:
140mA@24V
Inrush:
8.5Amp/0.7ms@24V
Environmental
Operating Temperature:
-40
o
C to 80
o
C
Storage Temperature:
-40
o
C to 85
o
C
Operating Humidity:
10% to 95%
(Non
Condensing)
Operating Altitude:
0 to 10,000 ft.
Network Media
10BaseT: >Cat3
Cable
100BaseTX: >Cat5
Cable
100BaseFX
Multimode:
50-62.5/125μm
Singlemode:
7-10/125μm
Connectors
10/100BaseTX:
One (1) RJ-45 TX Port
100BaseFX:
One (1) ST or SC Duplex Port
Recommended Wiring Clearance
Front:
5"
(12.7
cm)
Top:
1"
(2.54
cm)
100 Mb Fiber Transceiver Characteristics
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
Fiber Length
2km*
15km**
40km**
80km**
TX Power Min
-19dBm
-15dBm
-5dBm
-5dBm
RX Sensitivity Max
-32dBm
-34dBm
-34dBm
-34dBm
Wavelength
1310nm
1310nm
1310nm
1550nm
Ordering Information
102MC-XX 100BaseFX
multimode
fi ber
102MCE-XX-YY
100BaseFX singlemode fi ber
NTPS-24-1.3
DIN-Rail Power Supply
Where "XX" is: ST for ST style fi ber connector
SC for SC style fi ber connector
Where "YY" is: 15 for 15km max. fi ber segment length
40 for 40km max. fi ber segment length
80 for 80km max. fi ber segment length
N-TRON Corp.
N-TRON Europe GmbH
820 S. University Blvd., Suite 4E Alte Steinhauserstr 19
Mobile, AL 36609 USA
6330 Cham / Zg Switzerland
TEL: (251) 342-2164
TEL: +41 41 7406636
FAX: (251) 342-6353
FAX: +41 41 7406637
Website: www.n-tron.com
Email: [email protected]
Contact Information
Regulatory Approvals
FCC Title 47 Part 15 Subpart BClass A
ICES-003- Class A
CE: EN61000-6-2,4
EN61000-4-2,3,4,5,6
UL Listed (US and Canada) per ANSI/ISA-12.12.01-2000,
Class I, Div 2, Groups A,B,C,D,T5;
EN55011 Class A
GOST-R Certifi ed
RoHS Compliant
ABS Type Approval for Shipboard Applications
DNV Type Approval Certifi cation
EN50155 for Railway Applications
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/TS2 for Traffi c Control Equipment
