222 North Union Street • Bryan, Ohio 43506
(419) 636-4217 • Fax (419) 636-2450
http://enclosures.alliedmoulded.com
AMU664, NEMA Type 4X, Fiberglass Reinforced Polyester Enclosure
• Compression molded fiberglass reinforced polyester construction with flush, solid/opaque cover
• Allied Moulded Ultraguard ® fiberglass reinforced polyester material formulation
- UV stabilized for outdoor use
• Light gray color (RAL 7035)
• Clear, polycarbonate instrumentation cover
• 304 stainless steel captive cover screws, lockable latches, and hinge pin
• Partially molded hinge and molded latch keeper
• Gasket made of closed cell neoprene cord encased in a continuous tongue and groove channel
• Polycarbonate flanges (installed) and mounting feet (bagged) with four 304 stainless steel screws
• 10-32 threaded brass inserts are installed for back panel mounting
C O N S T R U C T I O N C O N S T R U C T I O N
A P P L I C A T I O N A P P L I C A T I O N
S T A N D A R D S S T A N D A R D S
• Construction meets NEMA/EEMAC Type 4, 4X, 12 Specifications
• UL ® 508 and UL ® 50 listed, Type 1, 2, 3, 3R, 4, 4X, 12, 13
• CSA certified file LR 89590-1
• Enclosure flammability rating per UL
® 508
• Joint Industrial Council (JIC) enclosure sizing
• Compliant with RoHS directive
6” x 6” x 4” 6” x 6” x 4”
• Designed to insulate and protect controls and components in both indoor and outdoor applications
often found in oil refineries, waste water treatment equipment, and chemical plants
• Especially well suited for high temperature or corrosive environments
• Protects from dirt, dust, oil, and water
• For use with industrial control equipment in ordinary locations
• Clear/polycarbonate, instrumentation cover used in applications where critical electronic equipment
must be visible and protected from the elements
Screw Cover Hinged Screw Cover Hinged Snap Latch Hinged Twist Latch
Solid/Opaque AMU664F AMU664HF AMU664LF AMU664TF
Clear Cover AMU664CCF AMU664CCHF AMU664CCLF AMU664CCTF
View Window AMU664WF AMU664HWF AMU664LWF AMU664TWF
Screw Cover Hinged Screw Cover Hinged Snap Latch Hinged Twist Latch
Solid/Opaque AMU664 AMU664H AMU664L AMU664T
Clear Cover AMU664CC AMU664CCH AMU664CCL AMU664CCT
View Window AMU664W AMU664HW AMU664LW AMU664TW
• Flange mount enclosures (flanges installed)
• Foot mount enclosures (four feet bagged and shipped inside enclosure)
Ordering Part Numbers
