Ordering Information
4664 Lougheed Highway Suite 221 Burnaby BC V5C 5T5 T:604-638-3920 F:604-638-3930 E:[email protected]
© 2007 Icron Technologies Corporation US Patent 6,381,666 B1 Document # 90-00101-B04
Specifications subject to change without notification
USB Rover products are supplied complete with a Local Extender (LEX)
unit, a Remote Extender (REX) unit, a USB cable, mounting hardware and
Name Part Number Description
USB Rover 1650 00-00084G 1-port extender
USB Rover 2650 00-00085G 2-port extender
Specifications
Range (over Category 5 UTP cable) 50 meters (165 ft)
# USB device ports (at REX) Rover 1650: 1
Rover 2650: 2
USB device support
(connected directly to REX) Any full-speed (12 Mb/s) or low-speed (1.5 Mb/s) de-
vice
USB hub support Up to 3 hubs can be connected in series with the Rover
1650/2650. Each hub reduces the maximum range by
10 meters.
Maximum power available to USB at REX 300 mA when LEX is supplied with 500 mA
USB cable 2 meters (6.6 ft)
LEX connector (upstream) 1 x USB Type B
LEX connector (downstream) 1 x RJ-45
REX connector (upstream) 1 x RJ-45
REX connector (downstream) Rover 1650: 1 x USB Type A
Rover 2650: 2 x USB Type A
LEX dimensions 100 mm x 70 mm x 30 mm (4.0” x 2.8” x 1.2”)
LEX weight 0.1 kg (0.2 lb)
REX dimensions 100 mm x 70 mm x 30 mm (4.0” x 2.8” x 1.2”)
REX weight 0.1 kg (0.2 lb)
Total system shipping weight 0.4 kg (0.8 lb)
Temperature range 4°C to 40°C
Regulatory testing FCC, CE Class B
